Radar installation video


Sensor connection


Firstly, check if the required materials are complete. You need to use a computer, power supply, wireless keyboard and mouse, graphics card adapter, HDMI cable, network connectivity, USB adapter, radar, radar power supply, network cable, and projector. First, connect the power supply of the computer projector and radar using network connectivity and network cable to connect the radar to the USB adapter and computer. Finally, connect the projector and computer graphics card using HDMI cable to complete the installation.


WALL


How to install lidar on the wall

The radar is designed to be detachable, and by removing the exposed screws and the base, it can be transformed into a wall version. Installing the base is the ground version.

 How to debug wall install single-lidar

After connecting the radar, it is necessary to first modify the IP address, change the radar address to the correct address, check if the radar is connected, then install the radar application software, open the device manager to add the device for saving, and manually test and adjust the specific parameters in the real-time recognition area of the device to adjust the radar.

How to debug wall install multi-lidar

As explained above, first complete the installation and debugging of multiple radars, and then install the fusion software. The software will divide the screen into grids, requiring manual touch of different squares to debug radar recognition.

FLOOR


How to install lidar on the floor

The ground installation of LiDAR is similar to wall installation, simply install the base of the radar and fix it to the ground using the same method.

How to debug ground single lidar


ground single lidar


Lidar sensor connection


Lidar sensor connection

The above is the radar equipment installation and debugging tutorial, including radar line connection, how to install radar on the ground, how to install radar on the wall, how to debug radar software, etc., in order to cope with your correct installation and debugging of radar equipment in various environments, so that installation and debugging are wordless
